Structural Model
22.2.0_SAF_various_spring_prop
The following enhancements of the various spring properties definitions have been added:
- • Linear, Gap, Hook, and Multi-linear Elastic link properties are now available in the program for use in specification of spring properties.
- • It’s now possible to directly specify nonlinearity for point springs, or to base the nonlinearity on an existing Link property.
- • For line and area spring properties, spring stiffness and nonlinearity can now be either directly entered by the user or based on an existing Link property.
Design
22.2.0_SAF_comp_beam_design_IS11384_BG50017
Composite Beam Design codes have been added for the Indian IS 11384:2022 and the Chinese GB50017 codes.
22.2.0_SAF_punching_shear_report
The formatting of the punching-shear design report has been enhanced for all codes. The report now shows a detailed design procedure that includes all the implemented equations with references to the code.
User Interface
22.2.0_SAF_object_display_color
An enhancement has been added to display objects by color based on the spring properties assigned to them. This option for display is available under View > Set Display Options. If an object does not have any spring assignment, it is shown in dark gray color.
22.2.0_SAF_slab_detailing_info_right_click
Overwrites and detailing information for concrete beams and slab design strips can now be viewed in the right click information forms.
Analysis
22.0.0_SAF_walking_vibrations
Serviceability assessment of steel-framed floor systems subjected to walking vibrations according to AISC Design Guide 11, Chapter 7 has been added.
Graphics
22.0.0_SAF_offset_joint_assignment
An enhancement was made to show the effects of joint offset assignments for slabs (when shown in an extruded view). Joint offsets can be assigned using the command Assign > Shell > Insertion Point. The effect of the cardinal point was previously included in extruded views, but not the additional joint offsets.
Structural Model
22.0.0_SAF_curved_beam_to_shell
Conversion of curved concrete beams to shell slabs is now available. Previously, only straight beams could be converted.
Design
22.0.0_SAF_composite_steel_AISC-360-22
Composite beam design per AISC 360-22 design code has been added.
Material Libraries & Databases
22.0.0_SAF_frame_sec_AISC
New frame section libraries have been added conforming to AISC Shapes Database v16.0.
Application Programming Interface (API)
22.0.0_SAF_api_.NET8
The SAFE API has been updated to support .NET 8.
User Interface
21.2.0_SAF_drawing_linear_tendon
An enhancement has been implemented to allow drawing a linear tendon throughout between two points. Two options are now available in the Drawing Properties window for the vertical profile when drawing a tendon: Linear Throughout and Program Determined (current default).
Cloud Sign-in Licensing
21.2.0_SAF_cloud_sign_in_lic
Cloud Sign-in licensing is now available
- • Access CSI software using secure user credentials — no more activation keys
- • Access licenses anywhere with internet access
- • Option to create License Groups to manage who has access to your licenses
- • Option to remotely terminate an active license session
- • Option to federate your identity provider (IdP), allowing users to use their familiar company credentials instead
Data Files
21.1.0_SAF__JTJ/T-483-2020_chinese_mat
JGJ/T 483-2020 high-strength steel materials have been added to the Chinese material library.
Drafting and Editing
21.1.0_SAF_snap_only
An enhancement has been implemented to allow drawing of objects in the graphical user interface using a snap-only option. When enabled, objects may be drawn only if the cursor snaps to an item, which can be used in combination with various snap options to accurately control placement of objects.
Output and Display
21.1.0_SAF_speed_up_display_strip_forces
An enhancement has been made to speed up display of strip forces, strip-force tables, and concrete slab design on models with many load combinations.
Detailing
21.0.0_SAF_detailing_menu
Detailing of concrete and steel structures, as well as the production and management of schematic design drawings, is now available from a new Detailing menu inside SAFE.
21.0.0_SAF_detailing_revit_reinforcement
Detailed reinforcement from beams and slabs can now be exported from SAFE to Autodesk® Revit® through the CSiXRevitTM 2023 plugin to Revit 2023.
Design
21.0.0_SAF_tributary_PT_tendon
Tributary PT tendons are now accounted for in finite element-based design of slabs and cracked-slab deflection analysis (short- and long-term).
Output and Display
21.0.0_SAF_crack_sec_modifiers_database
Cracked-section modifiers for beam and floor objects are now included in the database tables.
Design
20.3.0_SAF_concrete_csa_a23.3-19
The concrete code “CSA A23.3-19” has been added for reinforced-concrete and post-tensioned slab design.
20.3.0_SAF_nzs_310-06
Reinforced-concrete and post-tensioned slab design have been updated for the NZS 3101-06 code to accommodate Amendments 1 to 3.
20.3.0_SAF_concrete_slab_aci_318-19
A new concrete slab design preference is available for the "ACI 318-19" code to optionally set the depth-dependent shear-strength reduction factor, Lambda_s, to 1.0 for mats and footings per ACI 318-19 13.2.6.2.
20.3.0_SAF_longitudinal_rebar
Concrete frame design now reports and displays the longitudinal rebar required for detailing due to torsion and shear, in addition to the flexural rebar previously reported for detailing purposes.
Structural Model
20.3.0_SAF_steel_csa_g40.20-13
A built-in material library has been added for Canada with steel materials per the CSA G40.20-13/G40.21-13 standard, concrete materials per the CSA A23.3 standard, and rebar materials per the CSA G30.18:21 standard.
Output and Display
20.3.0_SAF_integrated_wall_reactions
Integrated wall reactions are now available for graphical display and in a new database table.
20.3.0_SAF_tendon_control_points
The display of tendon control points has been enhanced to show all control points within each span, and to display the vertical offset distance of tendon control points from the bottom of the slab (or drop, if present).
20.3.0_SAF_soil_pressures
Soil pressures are now available in the database tables on a joint-by-joint basis in addition to the enveloped values previously available on a slab-panel basis.
Application Programming Interface (API)
20.3.0_SAF_api_multiple_instances
The following enhancements have been made to the Application Programming Interface (API):
- • The client can attach to any running instance of SAFE given its process ID.
- • A new command "Set as active instance for API" has been added to the Tools menu.
- • A new interface cPluginContract has been added to simplify plugin development.
- • Speed has been improved for external .NET clients that call the API by chaining properties and methods in deeply nested loops.
Design
20.2.0_SAF_CSA S16-19_composite_design
The CSA S16-19 code has been added for composite beam design.
Structural Model
20.2.0_SAF_age_of_concrete
The age of concrete at which loading is applied can now be specified for long-term cracked-section analysis. Previously, the age at loading was assumed to be 7 days.
Analysis
20.2.0_SAF_rerun_analysis_design
Analysis and design will now be automatically rerun if cracked short-term or long-term deflection analysis is requested and a previous design to determine the amount of required rebar is not available.
Graphics
20.2.0_SAF_extruded_variable_thickness
Extruded views have been enhanced to show joint-offset overwrites for shell area objects.
Structural Model
20.1.0_SAF_tendons_mat_GB-50010-2010
Tendon materials are now available for the Chinese GB 50010-2010 standard.
Detailing
20.1.0_SAF_detailing_composite-beam_flrs
Detailing is now available for composite-beam floors. Detailing can be viewed and edited within the program, and the results used for further design checks.
20.1.0_SAF_detailing_PT_tendons_profile
Concrete slab and beam detailing is enhanced to include PT tendon profiles. This includes showing tendons and jacks in 3D views of slab reinforcement and the tendon profiles in beam elevations and sections.
20.1.0_SAF_detailing_PT_tendons_3d
20.1.0_SAF_detailing_BOQ
The detailing Bill of Quantities (BOQ) table now include the addition of quantities for steel beams and tendons.
20.1.0_SAF_detailing_grid_sys_available
General grid systems are now available in frame layout and rebar drawings for Detailling.
20.1.0_SAF_detailing_waffle_&_ribbed-slab
Waffle-slab and ribbed-slab detailing is enhanced to include the handling of reinforcement in waffles and ribs for small web widths, and the addition of a new rib-reinforcement view.
Drafting and Editing
20.1.0_SAF_measuring_tool
On-screen measuring tools are now available to measure line lengths, the angles between two lines, and the areas and perimeters of closed polygons.
20.1.0_SAF_editing_rebar_objects
On-screen editing of Rebar Objects can now be made/accomplished/done using the reshaping tool.
User Interface
20.1.0_SAF_design_quick_access_tool_buttons
Additional tool buttons for the main tool bar are now available for quick access to information on concrete slab design, concrete beam design, composite beam design, punching shear design, and crack width display.
Import and Export
20.1.0_dxf_floor_plans
The import of DXF files as floor plans has been implemented with the option to import joint locations from the file.
